📚 Complete Guide to Refrigeration Tons and BTU/hr

Understanding Refrigeration Tons and BTU/hr

Refrigeration tons and BTU/hr (British Thermal Units per hour) both measure cooling capacity—the rate at which heat is removed from a space or substance. 1 refrigeration ton = 12,000 BTU/hr, a conversion standardized in the HVAC industry with historical origins in ice production. The refrigeration ton originated from 19th-century ice manufacturing when mechanical refrigeration replaced natural ice harvesting. Definition: One ton of refrigeration equals the heat absorption required to melt one ton (2,000 pounds) of ice at 32°F (0°C) over 24 hours. Calculation: Ice has latent heat of fusion 144 BTU/lb (heat absorbed during phase change from solid to liquid without temperature change). Total heat: 2,000 lbs × 144 BTU/lb = 288,000 BTU to melt 1 ton ice. Rate: 288,000 BTU ÷ 24 hours = 12,000 BTU/hr cooling rate = 1 ton refrigeration capacity. This became the standard unit because early refrigeration systems replaced ice delivery for commercial cold storage, food preservation, and building cooling, making direct comparison essential. BTU/hr represents absolute heat removal rate: 1 BTU = heat required to raise 1 pound of water 1°F. BTU/hr measures steady-state cooling output: air conditioner removing 36,000 BTU/hr extracts that much heat continuously from conditioned space. Used for precise engineering calculations, equipment specifications, and energy analysis. Tons provide intuitive HVAC sizing: residential AC typically 1.5-5 tons (1.5 tons small apartment 600-900 sq ft; 2-2.5 tons house 1,200-1,800 sq ft; 3-4 tons house 1,800-2,500 sq ft; 4-5 tons house 2,500-3,500 sq ft); commercial systems 10-100+ tons (20-30 tons small office 5,000-10,000 sq ft; 50-100 tons retail 20,000-50,000 sq ft; 200-500 tons large building); industrial chillers 100-1,000+ tons (cooling towers, process cooling, data centers). Understanding both units enables HVAC professionals to specify equipment (3-ton residential split system = 36,000 BTU/hr), calculate cooling loads (8,000 sq ft office × 400 BTU/hr per sq ft = 3,200,000 BTU/hr ÷ 12,000 = 267 tons required), and compare systems (chiller plant 500 tons = 6,000,000 BTU/hr = 1,758 kW electrical input at 2.85 EER).

Conversion Formulas

Refrigeration Tons to BTU/hr: \( \text{BTU/hr} = \text{Tons} \times 12{,}000 \). Multiply refrigeration tons by 12,000 to convert to BTU per hour. Examples: 0.5 tons × 12,000 = 6,000 BTU/hr (window AC small room 150-250 sq ft); 1 ton × 12,000 = 12,000 BTU/hr (window AC medium room 400-550 sq ft, mini-split single zone); 1.5 tons × 12,000 = 18,000 BTU/hr (small apartment 600-900 sq ft, bedroom mini-split); 2 tons × 12,000 = 24,000 BTU/hr (house 1,200-1,500 sq ft, large room mini-split); 2.5 tons × 12,000 = 30,000 BTU/hr (house 1,500-1,800 sq ft); 3 tons × 12,000 = 36,000 BTU/hr (house 1,800-2,100 sq ft, typical residential central AC); 3.5 tons × 12,000 = 42,000 BTU/hr (house 2,100-2,400 sq ft); 4 tons × 12,000 = 48,000 BTU/hr (house 2,400-2,700 sq ft); 5 tons × 12,000 = 60,000 BTU/hr (house 2,700-3,500 sq ft, large residential system); 7.5 tons × 12,000 = 90,000 BTU/hr (small commercial 3,000-4,000 sq ft); 10 tons × 12,000 = 120,000 BTU/hr (commercial rooftop unit small retail/office 5,000-7,000 sq ft); 20 tons × 12,000 = 240,000 BTU/hr (commercial packaged unit 10,000-15,000 sq ft); 30 tons × 12,000 = 360,000 BTU/hr (commercial building section 15,000-20,000 sq ft); 50 tons × 12,000 = 600,000 BTU/hr (commercial chiller small building 25,000-35,000 sq ft); 100 tons × 12,000 = 1,200,000 BTU/hr (commercial chiller large building 50,000-75,000 sq ft); 200 tons × 12,000 = 2,400,000 BTU/hr (central plant chiller 100,000-150,000 sq ft); 500 tons × 12,000 = 6,000,000 BTU/hr (large central plant high-rise or campus 250,000-400,000 sq ft); 1,000 tons × 12,000 = 12,000,000 BTU/hr (major facility chiller plant data center or hospital). BTU/hr to Refrigeration Tons: \( \text{Tons} = \frac{\text{BTU/hr}}{12{,}000} \). Divide BTU per hour by 12,000 to convert to refrigeration tons. Examples: 6,000 BTU/hr ÷ 12,000 = 0.5 tons (½ ton small window unit); 9,000 BTU/hr ÷ 12,000 = 0.75 tons (¾ ton window AC); 12,000 BTU/hr ÷ 12,000 = 1 ton (1-ton mini-split or window unit); 18,000 BTU/hr ÷ 12,000 = 1.5 tons (1.5-ton residential AC); 24,000 BTU/hr ÷ 12,000 = 2 tons (2-ton central AC); 30,000 BTU/hr ÷ 12,000 = 2.5 tons; 36,000 BTU/hr ÷ 12,000 = 3 tons (most common residential size); 48,000 BTU/hr ÷ 12,000 = 4 tons; 60,000 BTU/hr ÷ 12,000 = 5 tons (large residential); 120,000 BTU/hr ÷ 12,000 = 10 tons (small commercial RTU); 240,000 BTU/hr ÷ 12,000 = 20 tons (commercial packaged); 600,000 BTU/hr ÷ 12,000 = 50 tons (commercial chiller); 1,200,000 BTU/hr ÷ 12,000 = 100 tons (large chiller); 6,000,000 BTU/hr ÷ 12,000 = 500 tons (central plant). This straightforward 12,000× multiplier enables HVAC professionals to quickly convert between tons (intuitive for system sizing and customer communication: "You need a 3-ton AC") and BTU/hr (precise for load calculations, equipment specifications, energy modeling: Manual J residential load 36,000 BTU/hr = 3 tons required).

HVAC Capacity Reference Table

HVAC Load Calculation and Sizing

Understanding tons-BTU/hr conversion enables proper HVAC system sizing through Manual J residential load calculations and commercial building analysis. Residential Cooling Load Example: 2,000 sq ft house, Climate Zone 3A (warm-humid southeastern US). Manual J load calculation factors: Building envelope (walls R-13, ceiling R-30, windows U-0.35 SHGC 0.30 double-pane low-e); Infiltration 0.35 ACH50 (air changes per hour at 50 Pa pressure difference); Internal gains (occupants 4 people × 230 BTU/hr sensible + 200 BTU/hr latent = 1,720 BTU/hr; appliances/lighting 2,500 BTU/hr); Design conditions (outdoor 95°F dry-bulb 75°F wet-bulb; indoor 75°F 50% RH). Sensible heat gains: Envelope conduction through walls/ceiling/floor = 12,000 BTU/hr; Solar radiation through windows south/west exposure = 8,500 BTU/hr; Infiltration/ventilation outdoor air = 4,200 BTU/hr; Internal gains occupants/equipment = 4,220 BTU/hr. Total sensible = 28,920 BTU/hr. Latent heat gains: Infiltration/ventilation moisture = 3,800 BTU/hr; Occupant perspiration = 800 BTU/hr. Total latent = 4,600 BTU/hr. Total cooling load: 28,920 + 4,600 = 33,520 BTU/hr ÷ 12,000 = 2.79 tons. System selection: 3-ton (36,000 BTU/hr) standard size provides 7.4% oversizing acceptable for peak conditions and dehumidification. Equipment specification: 3-ton 16 SEER split system with variable-speed compressor; sensible heat ratio SHR 0.75 matches load (28,920 ÷ 36,000 = 0.80 close to 0.75 equipment rating ensuring proper latent removal/dehumidification). Airflow: 3 tons × 400 CFM/ton = 1,200 CFM (350-450 CFM/ton range for proper dehumidification; lower end 350 CFM/ton = 1,050 CFM for high latent loads humid climates; higher 450 CFM/ton = 1,350 CFM for dry climates prioritizing sensible cooling). Duct sizing: 1,200 CFM ÷ 700 FPM velocity = 1.71 sq ft = 16" diameter trunk or 20"×12" rectangular supply plenum. Commercial Building Cooling Load: 20,000 sq ft office building, Climate Zone 4A (mixed-humid). Load factors: Occupancy density 5 people per 1,000 sq ft = 100 people × 250 BTU/hr per person = 25,000 BTU/hr; Lighting 1.2 W/sq ft × 20,000 × 3.41 BTU/W = 81,840 BTU/hr; Plug loads 1.0 W/sq ft × 20,000 × 3.41 = 68,200 BTU/hr; Solar gains east/south/west windows 150,000 BTU/hr peak; Envelope conduction 80,000 BTU/hr; Ventilation 20 CFM/person × 100 people = 2,000 CFM outdoor air × 18 BTU/hr per CFM enthalpy difference = 36,000 BTU/hr sensible + 24,000 BTU/hr latent. Total cooling load: (150,000 + 80,000 + 81,840 + 68,200 + 36,000) sensible = 416,040 BTU/hr sensible + (25,000 + 24,000) latent = 49,000 BTU/hr latent. Total: 465,040 BTU/hr ÷ 12,000 = 38.75 tons. System selection: (2) 20-ton rooftop units = 40 tons total (480,000 BTU/hr) provides redundancy and zone control (north/south exposure differences). Each RTU: 20 tons = 240,000 BTU/hr capacity; 10.5 EER efficiency = 240,000 ÷ 10.5 = 22.86 kW electrical input; 8,000 CFM airflow = 400 CFM/ton; economizer for free cooling when outdoor conditions favorable (outdoor air < 55°F or outdoor enthalpy < indoor).
